Used CX165L Industrial Robot With E02 Controller For Kawasaki Welding Solution
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | YASKAWA |
| Certification: | CE,ROHS |
| Model Number: | CX165L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiable |
| Packaging Details: | Regular packing ,100% Factory Sealed. |
| Supply Ability: | 10 Set/Sets per Month |
|
Detail Information |
|||
| Condition: | New | Applicable Industries: | Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Construction Works |
|---|---|---|---|
| Showroom Location: | Turkey, United States, Viet Nam, Brazil, India, Russia, Argentina, South Africa, Australia | Warranty: | 1 Year |
| Key Selling Points: | Automatic | Voltage: | 220v |
| Current: | 15A | Rated Capacity: | 3500 W |
| Rated Duty Cycle: | Full Day | After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service |
| Local Service Location: | Canada, United Kingdom, United States, Viet Nam, Brazil, Peru, Indonesia, Russia, Argentina | After-sales Service Provided: | Field Installation, Commissioning And Training, Field Maintenance And Repair Service, Video Technical Support, Online Support |
| Product Name: | 6 Axis Arc Welding Robot From China | Number Of Axes: | 6 |
| Material: | Aluminum Alloy | Protection Rating: | IP40 |
| Port: | Shanghai | ||
| High Light: | CX165L Used Industrial Robot,Aluminum Alloy Kawasaki Welding Industrial Robot,Reach 269 Mm Used Kawasaki Robot |
||
Product Description
Educational robotic arm and robot arm reach 269 mm CX165L industrial welding robot with E02 Controller for Kawasaki
SPECIFICATIONS
| CX165L SPECIFICATIONS | |||
| product name | Educational robotic arm and robot arm reach 269 mm CX165L industrial welding robot with E02 Controller for Kawasaki | ||
|---|---|---|---|
| Type | Articulated Robot | ||
| Degrees of Freedom (axes) | 6 | ||
| Payload (kg) | 165 | ||
| Max. Reach (mm) | 2,699 | ||
| Positional Repeatability (mm) | ±0.06 | ||
| Motion Range (°) | Arm Rotation (JT1) | ±160 | |
| Arm Out-in (JT2) | +80 - −60 | ||
| Arm Up-down (JT3) | +95 - −75 | ||
| Wrist Swivel (JT4) | ±210 | ||
| Wrist Bend (JT5) | ±120 | ||
| Wrist Twist (JT6) | ±360 | ||
| Max. Speed (°/s) | Arm Rotation (JT1) | 130 | |
| Arm Out-in (JT2) | 125 | ||
| Arm Up-down (JT3) | 125 | ||
| Wrist Swivel (JT4) | 180 | ||
| Wrist Bend (JT5) | 180 | ||
| Wrist Twist (JT6) | 280 | ||
| Allowable Moment (N•m) | Wrist Swivel (JT4) | 952 | |
| Wrist Bend (JT5) | 952 | ||
| Wrist Twist (JT6) | 550 | ||
| Allowable Moment of Inertia (kg•m2) | Wrist Swivel (JT4) | 99 | |
| Wrist Bend (JT5) | 99 | ||
| Wrist Twist (JT6) | 49.5 | ||
| Mass (kg) | 870 | ||
| Mounting | Floor | ||
| Installation Environment | Ambient Temperature (°C) | 0 - 45 | |
| Relative Humidity (%) | 35 - 85 (No dew, nor frost allowed) | ||
| Controller / Power Requirements (kVA) | America | E02 / 7.5 | |
| Europe | E02 / 7.5 | ||
| Japan&Asia | E02 / 7.5 | ||
Detailed Images
CX165L Robot
NEW GENERAL-PURPOSE LARGE PAYLOAD ROBOT
The CX165L robot has a payload capacity of 165 kg and is the mid-range model of the general-purpose CX series robots. The CX robots offer a large payload capacity and feature a robust, yet lightweight, hollow arm and a new smaller sized universal controller. The series high-speed and slim arm design was developed to suit a wide range of applications, from material handling to spot welding.
Applications:
Our Services
1.Swift delivery
For common parts, we can deliver the goods within 3 days
2.Original products
All the products we sell are from origin manufacturer. We will submit all the manufacturer documentation while we finish delivery.
3.Quality Assurance
4.Technical Support
Including inspection,repair and maintenance, we can give all kinds of technical support.
5.Quickly responce
Our staffs will keep 24h online and answer your question very quickly.
FAQ
Q.What is Your Payment Term?
A:Normally T/T 30% in advance, balance to be paidbefore delivery, We also support the trade assurance,OlA.
Q:What is Trade Assurance? A:Trade Assurance is a free service by Alibaba.comthat's designed to help create trust between buyers andsuppliers.Trade Assurance helps buyers in the event ofshipping and quality-related dispute.
Q:Does Trade Assurance Charge Fees? A:No.Trade Assurance is free for both buyers andsuppliers.
Q:What Kind of Trade Terms Can You Do?
A:EX-WORKS,FOB,CFR,CIF,etc.
Want to Know more details about this product
