KUKA Small Industrial Robot KR 3 AGILUS Handling Robot
Product Details:
| Place of Origin: | Shanghai, China |
| Brand Name: | KUKA |
| Certification: | CE |
| Model Number: | KR 3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $25,000.00/sets >=1 sets |
| Packaging Details: | one KUKA small industrial robot KR 3 AGILUS top performance 6 axis material handling robot packing with fumigation wooden frame, WG:26.5KG<br>Controller and other parts packing with brown box, WG: 40KG<br>Total WG:66.5KG(>VG) |
| Supply Ability: | 5 Piece/Pieces per Month |
|
Detail Information |
|||
| Product Name: | KR 3 540 | Number Of Axes: | 6 |
|---|---|---|---|
| Max Payload: | 3kg | Maximum Reach: | 541 Mm |
| Pose Repeatability(ISO 9283): | ± 0.02mm | Ambient Temperature During Operation: | 5 °C To 45 °C (278 K To 318 K) |
| Mounting Position: | Floor; Ceiling; Wall; Desired Angle | Weight: | Approx. 27 Kg |
| Footprint: | 179 Mm X 179 Mm | Protection Rating: | IP40 |
| Condition: | New | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | New Product 2020 |
| Warranty Of Core Components: | 1 Year | Core Components: | Engine, Bearing, Motor, Gear |
| After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service | Local Service Location: | United Kingdom, United States, France, Germany, Pakistan, Russia, Spain, Japan, Romania |
| Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Printing Shops, Construction Works , Energy & Mining | Showroom Location: | United Kingdom, United States, Italy, France, Germany, Philippines, Brazil, India, Mexico, Russia, Spain, Algeria, Japan, Australia, Morocco |
| Warranty: | 1 YEAR | Port: | Shanghai |
| High Light: | KUKA small industrial robot,kuka small robot arm,small industrial robot KR 3 |
||
Product Description
KUKA small industrial robot KR 3 AGILUS top performance 6 axis material handling robot
Main Specifications
Model: KR 3 AGILUS
Maximum reach:541 mm
Maximum payload:3 kg
Pose repeatabilit: ± 0.02mm
Number of axes :6
Weight:approx. 26.5 kg
Protection rating:IP40
| Production Name | KR 3 AGILUS industrial robot arm |
| Model | KR 3 540 |
| Application | electronic robot arm |
| Maximum reach | 541 mm |
| Maximum payload | 3kg |
| Pose repeatability (ISO 9283) | ± 0.02 mm |
| Number of axes | 6 |
| Mounting position | Floor; Ceiling; Wall; Desired angle |
| Footprint | 179 mm x 179 mm |
| Weight | approx. 26.5 kg |
| Protection rating | IP40 |
| Controller | KR C4 compact |
| Motion range | |
| A1 | ±170 ° |
| A2 | -170 ° / 50 ° |
| A3 | -110 ° / 155 ° |
| A4 | ±175 ° |
| A5 | ±120 ° |
| A6 | ±350 ° |
Features:
- Maximum reach: 541 mm
- Rated payload: 3 kg
- Pose repeatability: ±0.02 mm
- Number of axes: six
- Mounting position: floor, ceiling, wall, and angle
- Robot footprint: 179 mm x 179 mm
- Weight (excluding controller): approximately 26 kg
Applications:
- Handling for other machines
- Plastics processing machines
- Measuring, testing, and inspection
- Handling for metal die-casting machines
- Palletizing
- Forging and bending
- Other handling operations
- Cutting machine tools
- Packaging and order picking
- Application of adhesives, sealants, or similar materials
- Other coating operations
- Fastening and pressing assembly
- Inserting and mounting other assembly processes
- Other machining operations
