6 Axis Material Removal Used Robot Arm RS050N Logistic Robot For Kawasaki
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | KAWASAKI |
| Certification: | CE |
| Model Number: | RS050N |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | negotiable |
| Packaging Details: | ONE Industrial Robots FD-V6S As OTC Welding Equipment Of 7 Axis Robot Arm Robotic Welding Machine packing with fumigation wooden frame. |
| Delivery Time: | 6-8working days |
| Payment Terms: | L/C, D/A, D/P, T/T |
| Supply Ability: | 999 sets/month |
|
Detail Information |
|||
| Name: | Robot Welding Workstation OTC FD-V25 6-axis Robot Is Designed For Arc Welding, Material-handling Automatic Welding Robot | Brand: | KAWASAKI |
|---|---|---|---|
| Model: | IRB2600 | Production Year: | 2000-2015 |
| Warranty: | 3 Month | Reach: | 2100mm |
| Payload: | 50kg | Reapetability: | 0.04 Mm |
| Axis: | 6 | Weight: | 600KG |
| High Light: | Material Removal Used Robot Arm,RS050N logistic robot KAWASAKI,Kawasaki Used Robot Arm |
||
Product Description
6 axis material removal robotic arm price and robotic machine RS050N logistic robot for Kawasaki
| RS050N SPECIFICATIONS | |||
| Type | Articulated Robot | ||
|---|---|---|---|
| Degrees of Freedom (axes) | 6 | ||
| Payload (kg) | 50 | ||
| Max. Reach (mm) | 2,100 | ||
| Positional Repeatability (mm) | ±0.06 | ||
| Motion Range (°) | Arm Rotation (JT1) | ±180 | |
| Arm Out-in (JT2) | +140 - −105 | ||
| Arm Up-down (JT3) | +135 - −155 | ||
| Wrist Swivel (JT4) | ±360 | ||
| Wrist Bend (JT5) | ±145 | ||
| Wrist Twist (JT6) | ±360 | ||
| Max. Speed (°/s) | Arm Rotation (JT1) | 180 | |
| Arm Out-in (JT2) | 180 | ||
| Arm Up-down (JT3) | 185 | ||
| Wrist Swivel (JT4) | 260 | ||
| Wrist Bend (JT5) | 260 | ||
| Wrist Twist (JT6) | 360 | ||
| Allowable Moment (N•m) | Wrist Swivel (JT4) | 210 | |
| Wrist Bend (JT5) | 210 | ||
| Wrist Twist (JT6) | 130 | ||
| Allowable Moment of Inertia (kg•m2) | Wrist Swivel (JT4) | 28 | |
| Wrist Bend (JT5) | 28 | ||
| Wrist Twist (JT6) | 11 | ||
| Mass (kg) | 555 | ||
| Mounting | Floor, Ceiling | ||
| Installation Environment | Ambient Temperature (°C) | 0 - 45 | |
| Relative Humidity (%) | 35 - 85 (No dew, nor frost allowed) | ||
| Controller / Power Requirements (kVA) | E02 / 7.5 | ||
| Protection | Wrist : IP67 equivalent / Base axis : IP65 equivalent | ||
